Technical Specifications Read the product brief
Essentials
Code Name
Products formerly JUNE CANYON
Status
Launched
Q1’18
Board Form Factor
UCFF (4″ x 4″)
Socket
Soldered-down BGA
Internal Drive Form Factor
2.5″ Drive
# of Internal Drives Supported
1
14
10.0 W
DC Input Voltage Supported
12-19 VDC
Processor Included
Warranty Period
3
Supplemental Information
Description
Other features: Includes SDXC card slot, dual microphones
Memory & Storage
DDR4-2400 1.2V SO-DIMM
38.4 GB/s
Graphics Specifications
2x HDMI 2.0a
# of Displays Supported ‡
2
Expansion Options
SDXC with UHS-I support
I/O Specifications
# of USB Ports
6
2.0, 3.0
USB 2.0 Configuration (External + Internal)
0 + 2
USB 3.0 Configuration (External + Internal)
2B 2F + 0
Max # of SATA 6.0 Gb/s Ports
1
Audio (back channel + front channel)
7.1 digital; L+R+mic (F); L+R+TOSLINK (R)
10/100/1000
Integrated Wifi
Intel® Wireless-AC 9462
Integrated Bluetooth
Yes
S/PDIF Out Connector
TOSLINK
CEC, 2x USB2.0, AUX_PWR, FRONT_PANEL
Package Specifications
Low Halogen Options Available
See MDDS
Advanced Technologies
No
