Ubiquiti UniFi Device Bridge
€ 113,95
10 op voorraad
Ubiquiti UniFi Device Bridge – wireless bridging PoE adapter
Device Bridge
UDB
Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link.
(1) GbE LAN port that provides up to 15W of PoE
5 GHz band with up to 867 Mbps throughput rate
Compatible with UniFi Protect PoE cameras, Talk phones, and various IoT devices via an Ethernet connection
Note. UniFi Consoles and APs must have the latest software updates installed.
| Mechanical | |
|---|---|
| Dimensions | 130 x 55 x 34 mm (5.1 x 2.2 x 1.3″) |
| Weight | 200 g (7.1 oz) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Hardware | |
| Management interface | WiFi |
| Networking interface | (1) GbE RJ45 port |
| PoE interface | (1) Passive PoE output |
| Button | (1) Factory-reset |
| LED | (4) Blue: signal (1) White/blue: indicator |
| Power method | 100—240V AC, 0.45A Max., 50/60 Hz |
| Max. power consumption | AC input: 25W Excluding PoE output: 10W |
| Max. PoE wattage per port | 15W |
| Supported voltage range | 100—240V AC |
| WiFi standards | 802.11a/n/ac |
| Max. TX power 2.4 GHz 5 GHz 6 GHz |
– 21 dBm – |
| MIMO 2.4 GHz 5 GHz 6 GHz |
– 2 x 2 – |
| Max. data rate 2.4 GHz 5 GHz 6 GHz |
– 866.7 Mbps (BW80) – |
| Antenna gain 2.4 GHz 5 GHz 6 GHz |
– Internal antenna : 5 dBi / External omni antenna : 4 dBi – |
| Antenna | (1) Internal antenna (1) RP-SMA connector for external omni-antenna |
| Mounting | Wall (Included) |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Supported Data Rates | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) |
| 802.11ac | 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
| Gewicht | 0,200 kg |
|---|---|
| Afmetingen | 13 × 5,5 × 3,4 cm |
