A battery-powered smart sensor capable of detecting motion, lighting, and environmental changes.

Features:

• • • Motion detection range: up to five meters (16 ft)
    • Temperature, light, humidity, and water-level* detection
    • Built-in accelerometer and magnetic entry sensor for detecting door/window openings
    • Detection alarm system**

Note: This sensor must be connected to an up-to-date Bluetooth-supported UniFi Access Point.

*Water sensor sold separately.
**Based on UL217 and UL2034 alarm patterns.

• Works with the UniFi Protect Application

• Plug-and-play installation
• Designed for scalability
• Intuitive user interface
• Powerful mobile app
• Subscription-free

• And much more

PRODUCT SUMMARY

Mechanical
Dimensions	Ø24 x 83.5 mm (Ø0.94 x 3.29″)
Weight	50.2 g  (1.77 oz)
Enclosure material	Polycarbonate
Mount materials	Flat wall mount: polycarbonate, adhesive Corner mount: polycarbonate, adhesive
Additional gear	Magnet Water sensor adapter (Only available in the 3-pack at general release.)
Hardware
Processor	MCU Processor at 40 MHz
Networking interface	Bluetooth 5.0, BLE
Max. TX power	5 dBm
Max. power consumption	77mW
Power method	Lithium battery CR123A
Sensor features	Motion sensor (5 m/16 ft max. range) Magnetic entry sensor for door or window open/close Accelerometer for garage door open/close Temperature sensor Humidity sensor Ambient light sensor Alarm sound sensor Water sensor for detecting leaks and floods (requires water sensor adapter accessory, only available in 3-pack at general release) BLE connectivity from access point in indoor setting (recommended range 15 m/49 ft, performance will vary based on environment)
Antenna	2.4GHz
Antenna gain	0.5 dBi
LEDs	R/B/W
Button	Factory reset
Operating temperature	0 to 45° C (32 to 113° F)
Operating humidity	10 to 90% noncondensing
Certifications	FCC, IC, CE
Software
UniFi OS application	UniFi Protect
Mobile app	UniFi Protect iOS™ and Android™
