Ubiquiti UniFi Switch Pro 24 PoE
€ 695,00
Ubiquiti UniFi Switch Pro 24 PoE – (24) 10/100/1,000 RJ45 ports, (2) 1/10G SFP+ Ethernet ports – 400W total PoE availability
1 op voorraad
Switch Pro 24 PoE
SKU: USW-Pro-24-PoE-EU
Datasheet
Installation GuideA 24-port, Layer 3 PoE switch.
Features:
-
-
- (16) GbE, PoE+ RJ45 ports
- (8) GbE, PoE++ RJ45 ports
- (2) 10G SFP+ ports
- (1) USP RPS DC input for power redundancy
- 400W total PoE availability
-
Managed with the UniFi Network application: Version 5.10.5 and later
- Works with the UniFi Network Application
- Centrally manage multiple networks from an intuitive interface
- Enjoy real-time device insights and deep configuration options
- Upgrade device firmware remotely
- Manage network users and guests with ease
- Personalize the design, architecture, and privacy of guest hotspots
- Set up devices quickly and manage them on the go with a powerful mobile app
PRODUCT SUMMARY
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72″) |
| Weight | Without mounting brackets: 4.30 kg (9.48 lb) With mounting brackets: 4.39 kg (9.68 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Networking interface | (24) 10/100/1,000 RJ45 ports (2) 1/10G SFP+ Ethernet ports |
| Management interface | Ethernet In-Band |
| Total non-blocking throughput | 44 Gbps |
| Switching capacity | 88 Gbps |
| Forwarding rate | 65.472 Mpps |
| Power method | Universal input, 100—240V AC/50-60 Hz USP RPS DC input, 52V DC, 7.69A; 11.5V DC, 2.61A |
| Power supply | AC/DC, internal, 450W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 50W (Excluding PoE output) |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Shock and vibration | ETSI300-019-1.4 Standard |
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE Speed/link/activity |
| SFP+ | Link/activity |
| PoE | |
| Total available PoE | 400W |
| PoE interfaces Ports 1-16 Ports 17-24 |
PoE/PoE+(pins 1, 2+; 3, 6-) 60W PoE++ (Pins 1, 2+; 3, 6-) (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎 |
| Max. PoE wattage per port by PSE PoE+ PoE++ |
32W 64W |
| Voltage range PoE mode | 44—57V |
| Voltage range PoE+ mode | 50—57V |
INSTRUCTIONS AND MANUALS
| Gewicht | 4,39 kg |
|---|---|
| EAN | 0817882027649 |
