MASTERBOX MB320L ARGB
BETTER AFTER DARKMIRROR
DarkMirror Front Panel
Mesh Intakes
Dual ARGB Fans
Tempered Glass Side Panel
Adaptable Drive Cage
Versatile Cooling Options
Room For Upgrades
ARGB CONTROLLER
The small ARGB Controller is a mini-sized controller that allows your Addressable RGB such as fans and LED strips to be powered and controlled even in PC systems without an A-RGB capable motherboard.
The controller comes with 14 lighting presets to make full use of the Addressable LEDs in the system and also allows to be completely switched off by long pressing its button.
It is also possible to attach any external 2pin button to it to be able to switch presets without having to open the system. For ease of use, Cooler Master allows the RESET button to be optionally connected to the controller and used as an external ARGB preset switch button.
- MODEL NUMBER
- MCB-B320L-KGNN-S01, MCB-B320L-KGNN-S02
- SERIES
- MasterBox Series
- SIZE
- Mini Tower
- AVAILABLE COLOR(S)
- Black
- MATERIALS
- Steel, Mesh, Plastic, Tempered Glass
- DIMENSIONS (L X W X H)
- 435.5 x 217.5 x 410mm
- WEIGHT
- 5.47kg
- MOTHERBOARD SUPPORT
- Micro ATX, Mini ITX
- EXPANSION SLOTS
- 4
- 5.25″ DRIVE BAYS
- N/A
- 2.5″ / 3.5″ DRIVE BAYS (COMBO)
- 2
- 2.5″ DRIVE BAYS
- 2
- I/O PANEL
- 2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB 2-to-3 splitter, 1x ARGB Controller (only for the S02 versions)
- PRE-INSTALLED FANS – FRONT
- 2x 120mm ARGB Fan
- FAN SUPPORT – TOP
- 2x 120/140mm
- FAN SUPPORT – FRONT
- 3x 120mm, 2x 140mm
- FAN SUPPORT – REAR
- 1x 120mm
- RADIATOR SUPPORT – TOP
- 120mm, 240mm
- RADIATOR SUPPORT – FRONT
- 120mm, 140mm, 240mm, 280mm
- RADIATOR SUPPORT – REAR
- 120mm
- CLEARANCE – CPU COOLER
- 166mm/6.54″
- CLEARANCE – PSU
- 140mm (HDD cage in backmost position), 325mm (w/o front radiator & HDD cage)
- CLEARANCE – GFX
- 344mm
- CABLE ROUTING
- 18-22mm
- DUST FILTERS
- Top, Bottom, Front
- POWER SUPPLY SUPPORT
- Bottom mount, ATX
- WARRANTY
- 2 years
- EAN CODE
- 4719512097304, 4719512097601
- UPC CODE
- 884102069604, 884102069901
