• Graphics Processing
    Radeon RX 9070
  • Core Clock
    Boost Clock* : up to 2700 MHz (Reference card: 2520 MHz)
    Game Clock* : up to 2210 MHz (Reference card: 2070 MHz)
  • Stream Processors
    3584 ( 56CU)
  • Memory Clock
    20 Gbps
  • Memory Size
    16GB
  • Memory Type
    GDDR6
  • Memory Bus
    256 bit
  • Card Bus
    PCI-E 5.0
  • Digital max resolution
    7680 x 4320
  • Multi-view
    4
  • Card size
    L=288 W=132 H=50 mm
  • PCB Form
    ATX
  • DirectX
    DirectX 12 API
  • OpenGL
    OpenGL 4.6
  • Recommended PSU
    750W
  • Power Connectors
    8 pin*2
  • Output
    DisplayPort 2.1a x2
    HDMI 2.1b x2
  • Accessories
    VGA manual
* The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
